GR 4x4 Super T Pump

Super T Series®

Self-Priming, Solids-Handling Trash Pumps

Superior Solids-Handling

Designed for economical, trouble-free operation, the superior solids-handling capabilities of the Super T Series® pumps make them ideally suited for a variety of applications including solids-laden liquids and slurries. The large volute design allows automatic repriming in a completely open system without the need for suction or discharge check valves.

Pumps four inches and larger are engineered to allow up to three-inch diameter spherical solids to pass through any critical area, including the recirculation port.

Super T Series pumps are available in several configurations, including a B version for higher head applications, close-coupled or engine-driven models. All Gorman-Rupp Super T Series pumps are backed by a five-year manufacturer’s warranty.

Easy to maintain

Super T Series pumps are designed with ease of service in mind. Because they are self-priming, they can be mounted above the liquid being pumped. Should service or maintenance be required, it can be easily performed using common hand tools without disconnecting piping. The impeller, seal, wear plate and flap valve can all be accessed through the shimless coverplate opening for inspection or service.*

All Super T Series pumps can be coupled to a standard nEMA motor, which means there’s no waiting for special motors.

G-R Hard Iron

G-R hard iron is offered as an option for our popular Super T Series pumps and is available for your abrasive applications. for years, Gorman-Rupp has proclaimed the benefits of G-R hard iron. This durable material provides superior performance by extending the pump life up to six times over standard cast iron or ductile iron components. G-R hard iron has a measured hardness in excess of 400 Bhn (Brinnell), providing the best abrasion resistance for nearly all pumping application.
